Anritsu MT8801C - TX Measure Commands

2-19
2.5.5 TX Measure commands
(1) Setup TX Measure Parameter screen commands
• Setup TX Measure Parameter screen commands are valid at all the screens of the
TX/RX measurement.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
User Cal User Cal Factor UCAL UCAL? [dB/0.01dB] : -55.00 to 55.00 dB
TXUCAL TXUCAL? [dB/0.01dB] : -55.00 to 55.00 dB
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Closed Loop Power Control Bit Closed Loop PCBPAT CLP PCBPAT? CLP
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Power Control Pattern Alternate PCBPAT ALT PCBPAT? ALT
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
All ‘0’ PCBPAT ALL0 PCBPAT? ALL0
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
All ‘1’ PCBPAT ALL1 PCBPAT? ALL1
Auto PCBPAT AUTO PCBPAT? AUTO
User Define Level CLOSEDLOOPLVL CLOSEDLOOPLVL? [dBm/1dB] : -60 to 40dBm
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Power Measure Power Measure Power Meter PMTH POW PMTH? POW
Method Method IF Level Meter PMTH IF PMTH? IF
Access Probe Access Parameter PWR_STEP PWRSTEP PWRSTEP? :0 to 7dB
Access Parameter NUM_STEP NUMSTEP n NUMSTEP? n n:0 to 15
Access Parameter MAX RSP_SEQ MAXRSP n MAXRSP? n n:1 to 15
Measuring Period MEASPRIOD MEASPRIOD? nn: 1 to 999Frame
Measuring Number MEASNUM n MEASNUM? nn: 1 to 240
Calibration Calibration CALVAL CALVAL? f, f=0:Not calibrated
value f=1:Internal calibrated
f=2:External calibrated
:-10.00 to 10.00
Level Calibration LVLLINEACALVAL LVLLINEACALVAL? f, f=0:Not calibrated
Linearity value f=1:Internal calibrated
Calibration f=2:External calibrated
:[dBm/0.001dB]
RemarksQuery Msg
Intermediate
class
Function Program Msg
Response
Msg
Function details
2.5 Device Message List
