Anritsu MT8801C - Analog TX Measure Commands

Section 2 Device Messages
2-30
2.5.6 Analog TX measure commands
• Program messages for the analog TX measure command are valid in ranges defined
on each analog TX measure screen.
(1) Setup Analog TX Measure Parameter screen commands
User Cal User Cal Factor ATXUCAL ATXUCAL? [ dB / 0.01dB ]
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
RF measure RF measure mode All RFMM ALL RFMM? ALL
mode
RF Only RFMM RF RFMM? RF
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
AF Output Impedance 600Ω AOIMP 6ØØ AOIMP? 6ØØ
50Ω AOIMP 5Ø AOIMP? 5Ø
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Demod. output Range 40kHz RRNG 4ØK RRNG? 4ØK
terminal
4kHz RRNG 4K RRNG? 4K
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
(rear panel)
High Pass Filter 300Hz RHPF 3ØØ RHPF? 3ØØ
Off RHPF OFF RHPF? OFF
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Low Pass Filter 3kHz RLPF 3K RLPF? 3K
Off RLPF OFF RLPF? OFF
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
De-emphasis On RDEMP ON RDEMP? ON
Off RDEMP OFF RDEMP? OFF
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Squelch Auto RSQL AUTO RSQL? AUTO
Off RSQL OFF RSQL? OFF
Function details RemarksQuery Msg
Intermediate
class
Function
Response
Msg
Program Msg
