Section 2 Preparations Before Use
2-4
2.2.2 Maximum power to connector
The allowable maximum power to the MT8801C connectors are as follows.
Main Input/Output
AUX Input
AUX Output
AF Input
AF Output
DUT Interface
Reference Input
10MHz Buffered Output
Detector Output
BER Input connectors
Ext Trig Input
Ext Trig Output
Ext FM Input
Demod Output
Connector
10 W (40 dBm)
100 mW (20 dBm)
Exclusive output connector, 0.5 mW (–3 dBm)
30 Vrms
Dedicated output connector, 6 Vrms (output impedance:
600 Ω), 0.6 Vrms (output impedance: 50 Ω)
TTL level
2 to 5 Vp-p
Dedicated output connector, TTL level
Dedicated output connector, TTL level
TTL level
TTL level
Dedicated output connector, TTL level
±10 Vp-p
Dedicated output connector, ±8 Vp-p
Allowable maximum power
CAUTION
• Excessive power protection
Never apply power more than the allowable maximum
power. Also, do not input external signal to the output
connector.
