6.2 Instruments Required for Performance Test
6.2 Instruments Required for Performance Test
The instruments required for performance test are shown below.
Instruments Required for Performance Test
Synthesized signal
generator
(MG3633A)
Intelligent RF signal
generator (HP8665B)
Digital modulation signal
generator (MG3670B) +
CDMA modulation unit
(MG0310A)
Power meter (ML4803A)
Power sensor
(MA4601A)
Receiver for calibration
(ML2530A)
Programmable attenuator
(MN63A)
Digital mobile radio
transmission tester (MS8606A)
Recommended instrument
name (model name)
• Frequency range: 100 MHz to 2 GHz
1-Hz resolution available
• Output level range: –20 to +10 dBm
0.1-dB resolution available
• SSB phase noise: Maximum –130 dBc/Hz
(at 10 kHz offset)
• Second harmonics: Maximum –30 dBc
• External reference input:
(10 MHz available)
• Frequency range: 100 kHz to 3000 MHz
0.01-Hz resolution available
• Output level range: –139.9 to +13 dBm
0.1-dB resolution available
• SSB phase noise: Maximum –117 dBc/Hz
(at 20 kHz offset)
• Second harmonics: Maximum –30 dBc
• Frequency range: 300 MHz to 2250 MHz
1-Hz resolution available
• Output level range: –143 to +13 dBm
0.1-dB resolution available
• SSB phase noise: Maximum –120 dBc/Hz
(at 100 kHz offset)
• Second harmonics: Maximum –30 dBc
•
External reference input: 10 MHz or 13 MHz
• Main unit accuracy: ±0.02 dB
• Frequency range: 100 MHz to 8.5 GHz
(depending on the power sensor in use)
• Frequency range: 10 MHz to 3 GHz
• Measurement power range: –30 to +20 dBm
• Input connector: N-type
• Frequency range: 0.1 to 3000 MHz
• Level range: + 20 to –140 dBm
• Frequency range: DC to 2 GHz
• Maximum attenuation: 100 dB
(Attenuation width: 10 dB and 1 dB)
• Maximum input: 0.25 W (+24 dB)
• Vector error: Maximum 1.8% rms
Required performance
IF Level Meter measurement
accuracy
IF Level Meter measurement
accuracy
Power Meter measurement accuracy
Frequency/waveform quality
Neighboring spurious measurement
Spurious measurement
Relative level accuracy of signal generator
IF Level Meter measurement accuracy
Power Meter measurement accuracy
Relative level accuracy of signal generator
IF Level Meter measurement accuracy
Power Meter measurement accuracy
IF Level Meter measurement accuracy
IF Level Meter measurement accuracy
Waveform quality of signal generator
Test item
