2.5.8 Analog RX measure commands
• Program messages for the analog RX measure commands are valid in ranges de-
fined on each analog RX measure screen.
(1) Setup Analog RX Measure Parameter screen commands
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
AF Input Range 30V ARNG 30 ARNG? 30
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
4V ARNG 4 ARNG? 4
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
400mV ARNG 4ØØM ARNG? 4ØØM
40mV ARNG 4ØM ARNG? 4ØM
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Impedance 600Ω AIMP 6ØØ AIMP? 6ØØ
100kΩ AIMP 1ØØK AIMP? 1ØØK
User Cal User Cal Factor ARXUCAL
ARXUCAL? [dB/0.01dB]
2.5 Device Message List
Intermediate
class
Function
Program Msg Query Msg
Response
Msg
RemarksFunction details
