1.3 Example of System Configuration Using RS-232C/GPIB
1.3 Example of System Configuration Using RS-232C/GPIB
(1) Control by the host computer (1)
MT8801C
Radio Communication Analyzer
Host computer
RS-232C/GPIB
Printer
DUT
Parallel
RF
(2) Control by the host computer (2)
Host computer
DUT
Spectrum analyzer
MT8801C
Radio Communication Analyzer
RS-232C/GPIB RF
