Section 4 Operation
4-34
4.3.5 Setting the common measurement parameters: Setup Common
Parameter screen
• Switch to the Setup Common Parameter screen according to the following steps.
Set common measurement conditions on this screen.
Step Key operation Description
1. [Main Func on off] F6 Sets the Main Function on to display the Main Menu at the bottom of the
screen.
2. [TX&RX Tester] F1 Sets TX&RX Tester mode.
The Setup Common Parameter screen appears.
3. [TX Measure] F1 The TX Measure (for transmitter test) function keys appear on F7 to F12.
[RX Measure] F2 The RX Measure (for receiver test) function keys appear on F7 to F12.
[Call Processing] F3 The Call Processing (sequence monitor: operation status display) function
keys appear on F7 to F12.
Executable measurement varies depending on the Call Proc. State on the Setup Com-
mon Parameter screen, as below with the corresponding screen:
When the Call Proc. State is Stop, the following measurements can be executed:
TX Measure (Transmitter measurement)
Parameter setting Setup TX Measure Parameter screen
Template setting Setup Template screen
Power meter Power Meter screen
Occupied bandwidth measurement Occupied Bandwidth screen
Spurious close to the carrier measurement Spurious close to the Carrier screen
Spurious measurement Spurious Emission screen
TX Measure (Analog transmitter measurement)
Parameter setting Setup Analog TX Measure Parameter screen
RX Measure (Receiver measurement)
Parameter setting Setup RX Measure Parameter screen
Signal setting Setup Signal screen
RX Measure (Analog receiver measurement)
Parameter setting Setup Analog RX Measure Parameter screen
Call Processing (Call processing test)
Parameter setting Setup Call Processing Parameter screen
