Section 2 Device Messages
2-8
2.5 Device Message List
MT8801C-specific program commands, query messages, and response messages are
listed from paragraph 2.5.1.
• Device message table
(a) Program messages (Program Msg)/query message (Query Msg)
(i) Uppercase characters : Reserved words
(ii) Numeric : Reserved words (numeric code)
(iii) Lowercase characters in argument
f (frequency) : Real number or integer with decimal point
Units :GHZ, MHZ, KHZ, HZ, GZ, MZ,
KZ, no units = HZ
t (time) : Real number or integer with decimal point
Units :S, SC, MS, US, no unit = US
(level) : Real number or integer with decimal point
Units :DB, DBM, DM, DBU, W, MW, UW,
NW, no units = set SCALE units
n (no units integer) : Integer
r (no units real number) : Real number
h (no units hexadecimal number) :
Hexadecimal number
Others : Listed in remarks columns of the table
(b) Response messages (Response Msg)
(i) Uppercase characters : Reserved words
(ii) Numeric : Reserved words (numeric code)
(iii) Lowercase characters in argument
f (frequency) : 12-character fixed integer units = HZ
t (time) : Real number or integer with decimal point
(level) : Real number or integer with decimal point
u (ratio) : Real number or integer with decimal point
s (symbol) : Real number or integer with decimal point
n (no units integer) : Integer, variable number of digits
(Significant digits are output.)
r (no units real number) : Real number with decimal point, variable
number of digits (Significant digits are out-
put.)
h (no units hexadecimal number) :
Hexadecimal number
Others : Written in remarks columns of the table
Notes:
• Integer: NR1 format, real number: NR2 format
•Ø: Zero
