Section 1 General
1-4
1.4 RS-232C Specifications
The RS-232C specifications of the MT8801C are shown in the table below.
Item Specification
Function Control from an external controller
(except power switch)
Communication system Asynchronous (start-stop method), half-duplex
Communication control X-ON/OFF control
Baud rate 1200, 2400, 4800, 9600 bps
Data bits 7 bits, 8 bits
Parity Odd, Even, None
Start bit 1 bit
Stop bit 1 bit, 2 bits
Connector D-sub 9 pins, female
