4-35
4.3 CDMA Transmitter and Receiver Test --- TX and RX Tester Mode
When the Call Proc. State is Idle or Idle (Regist), the following measurements can be executed:
TX Measure (Transmitter measurement)
Parameter setting Setup TX Measure Parameter screen
Template setting Setup Template screen
Power meter Power Meter screen
Standby output power measurement Standby Output Power screen
Access Probe output power measurement Access Probe Measure screen
Occupied bandwidth measurement Occupied Bandwidth screen
Spurious close to the carrier measurement Spurious close to the Carrier screen
Spurious measurement Spurious Emission screen
TX Measure (Analog transmitter measurement)
Parameter setting Setup Analog TX Measure Parameter screen
RX Measure (Receiver measurement)
Parameter setting Setup RX Measure Parameter screen
Signal setting Setup Signal screen
RX Measure (Analog receiver measurement)
Parameter setting Setup Analog RX Measure Parameter screen
Call Processing (Call processing test)
Parameter setting Setup Call Processing Parameter screen
When the Call Proc. State is Loop Back or Conversation, the following measurements can be executed:
TX Measure (Transmitter measurement)
Parameter setting Setup TX Measure Parameter screen
Template setting Setup Template screen
Modulation analysis Modulation Analysis screen
Gated output power measurement Gated Power screen
Power meter Power Meter screen
Open-loop power-control time response measurement Open Loop Time Response screen
Occupied bandwidth measurement Occupied Bandwidth screen
Spurious close to the carrier measurement Spurious close to the Carrier screen
Spurious measurement Spurious Emission screen
TX Measure (Analog transmitter measurement)
Parameter setting Setup Analog TX Measure Parameter screen
Signal generator + Analog TX measurement Analog TX Meas with SG screen
RX Measure (Receiver measurement)
Parameter setting Setup RX Measure Parameter screen
Signal setting Setup Signal screen
Frame error rate (FER) measurement Frame Error Rate screen
RX Measure (Analog receiver measurement)
Parameter setting Setup Analog RX Measure Parameter screen
Analog RX measurement Analog RX Measure screen
Call Processing (Call processing test)
Parameter setting Setup Call Processing Parameter screen
When the Call Proc. State is Conversation (Service Option: SO1, SO3); the modula-
tion analysis, gated output power, open-loop power-control time response, and frame
error rate (FER) measurements cannot be executed:
Option 07: When a spectrum analyzer is mounted, this system changes to the spec-
trum analyzer mode and enables the user to observe the sending spectrum in progress
of loopback or conversion. In this case, note that the forward channel signal from this
device is also observed.
