2-29
(13) Setup Frequency Table commands
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Frequency Table Select Frequency Table File No. SLCTTBL n SLCTTBL? n n:0 to 99
Not Named --- SLCTTBL? NOT
Save Frequency Table File No. SAVETBL n --- --- n:0 to 99
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Frequency Modify F1 to F15 SPUFREQ fn,f SPUFREQ? fn f fn:F1 to F15
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Cancel SPUFREQ fn,0 --- ---
Harmonics SPUFREQ HRM --- ---
(14) Waveform memory read commands
• Waveform memory read commands are valid in all the modes of the MT8801C.
See Section 8 for such details as data format.
Gated Power Gated Power Mem D XMD p,b XMD? p,d b,b,b,.... *1,2,3
Open Loop
Open Loop Power Control Mem O XMO p,b XMO? p,d b,b,b,.... *1,2,3
Power Control
Occupied Spectrum Mem B XMB p,b XMB? p,d b,b,b,...
Bandwidth
FFT Mem E XME p,b XME? p,d b,b,b,...
Spurious close Spectrum Mem bw,B XMB bw,p,b XMB? bw,p,d b,b,b,... bw: RBW30,RBW1000,
to the Carrier
RBW1230
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Output format Output format ASCII BIN Ø --- ---
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
BIN OFF --- ---
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
BINARY BIN 1 --- ---
BIN ON --- ---
Note:
*1 Meaning of response Data → p: Index of waveform data save area
*2 Meaning of response Data → b: Waveform data
*3 Meaning of response Data → d: Number of data outputs
2.5 Device Message List
RemarksProgram Msg Query Msg
Intermediate
class
Function
details
Function
Response
Msg
RemarksQuery Msg
Intermediate
class
Function Program Msg
Response
Msg
Function details
