Anritsu MT8801C - Page 353

Section 2 Device Messages
2-28
Measure Result Adjacent Channel Power --- ADJCH? ps ps:LOW1,LOW2,
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
UP1,UP2
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
--- CHPWR? ps
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
--- ADJCH? ps,un un:DB,DBM,WATT
--- CHPWR? ps,un
Marker --- MKL? bw : Depends on
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
unit selected.
--- MKL? bw,un bw:RBW30,RBW1000,
RBW1230
un:DB,DBM,WATT
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Template PASS/FAIL PASS --- TEMPPASS? PASS
FAIL ---
TEMPPASS? FAIL
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
PASS --- TEMPRSLT? 1
FAIL ---
TEMPRSLT? 0
(11) Setup Spurious Template commands
Save Template File No. SAVESTEMP n --- --- n:0 to 99
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Level Modify Limit-1 STEMPLVL 1, TEMPLVL? 1 :-100.0 to 0.0dB
Limit-2 STEMPLVL 2, TEMPLVL? 2
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Relative/Absolute Relative SLVLREL ON SLVLREL? ON
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
MSTEMPREL ON MSTEMPREL? ON
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Absolute SLVLREL OFF SLVLREL? OFF
MSTEMPREL OFF MSTEMPREL? OFF
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Offset Frequency Modify Limit-1 TEMPFREQ A,f TEMPFREQ? A f f:0.10MHZ to 2.50MHZ
Limit-2 TEMPFREQ B,f TEMPFREQ? B f
(12) Spurious Emission commands
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Mode Spurious Mode Spot MEAS SPURIOUS,SPOT MEAS? SPURIOUS,SPOT
Search MEAS SPURIOUS,SEARCH MEAS? SPURIOUS,SEARCH
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Level Unit dB UNIT DB UNIT? DB
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
dBm UNIT DBM UNIT? DBM
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
mW UNIT MW UNIT? MW
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
uW UNIT UW UNIT? UW
nW UNIT NW UNIT? NW
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Frequency Table Save Frequency Table File No. SLCTTBL n SLCTTBL? n n:0 to 99
Not Named --- SLCTTBL? NOT
Adjust Range Adjust Range ADJRNG --- ---
Calibration Power Meter Calibration PWRCAL CALVAL? [dB/0.01dB]
Internal Osc. Calibration OSCCAL CALVAL? [dB/0.01dB]
Calibration Cancel CALCANCEL --- ---
Measure Result f1 to f15 ---
SPULVL? fn,po fn:F1 to F15
po:RBW3,RBW30,
○○○○○○○○○○○○○○○○○○○○○○○○
RBW1000
SPULVL?fn,po,un un: DBM, WATT, DB
RemarksProgram Msg Query Msg
Intermediate
class
Function details
Function
Response
Msg
RemarksProgram Msg Query Msg
Intermediate
class
Function
details
Function
Response
Msg
Remarks
Program Msg Query Msg
Intermediate
class
Function
details
Function
Response
Msg
