Section 2 Device Messages
2-20
(2) Access Probe Measure screen commands
• Program Msg of the Access Probe Measure screen commands are valid only at Ac-
cess Probe Measure screen.
Query Msg of the Access Probe Measure screen commands are valid at all the
screens of the TX/RX measurement screens.
Measure Start Access Probe Power APBSA --- ---
Stop Access Probe Power APBSO --- ---
BS Output Power Cal OLVLCAL --- ---
Calibration Internal Osc. Calibration OSCCAL CALVAL? [dB/0.01 dB]
Calibration Cancel CALCANCEL ---
Result Time --- APBTIME? p,d t,t,t,t,....t [frame]
Level --- APBLVL? p,d , , , ,... [dBm/0.01 dBm]
Number of bursts --- APBNUM? n [piece]
Note:
*1 Meaning of response Data → p: The start point of the access probe to be
read-out (AP number)
*2 Meaning of response Data → d: Number of data outputs
Remarks Query Msg
Intermediate
class
Function Program Msg Response MsgFunction details
