2-21
(3) Modulation Analysis screen commands
• Program Msg of the Modulation Analysis screen commands are valid only at Modu-
lation Analysis screen.
Query Msg of the Modulation Analysis screen commands are valid at all the screens
of the TX/RX measurement screens.
Calibration Power Meter Calibration PWRCAL CALVAL?
[dB/0.01 dB]
Internal Osc. Calibration OSCCAL CALVAL?
[dB/0.01 dB]
Calibration Cancel CALCANCEL --- ---
Adjust Range Adjust Range ADJRNG --- ---
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Closed Loop Power Control Bit
Closed Loop
PCBPAT CLP PCBPAT? CLP
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Power Control Pattern Alternate PCBPAT ALT PCBPAT? ALT
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
All ‘0’ PCBPAT ALL0 PCBPAT? ALL0
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
All ‘1’ PCBPAT ALL1 PCBPAT? ALL1
Auto PCBPAT AUTO PCBPAT? AUTO
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Closed Loop Up
CLOSEDLOOP UP
--- ---
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Power Control Down
CLOSEDLOOP DOWN
--- ---
User Define Level
CLOSEDLOOP USERLVL
--- ---
BS Output Power Cal
BS Output Power Cal OLVLCAL --- ---
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Storage Mode Storage Mode Normal STORAGE NRM STORAGE? NRM
Average STORAGE AVG STORAGE? AVG
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Average Count AVR n AVR? n n:2 to 9999
VAVG n VAVG? n n:2 to 9999
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Refresh Interval Every INTVAL EVERY INTVAL? EVERY
Once INTVAL ONCE INTVAL? ONCE
Result Carrier Frequency --- CARRF? f
[Hz/0.01 Hz]
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Carrier Frequency Error ---
CARRFERR?
f
[Hz/0.01 Hz]
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
---
CARRFERR? HZ
f
[Hz/0.01 Hz]
---
CARRFERR? PPM
u
[ppm/0.1 ppm]
ρ (Waveform Quality Factor) --- RHO? r
[–/0.00001]
τ (Timing Error) --- TAU? t
[µs/0.01 µs]
RMS Vector Error --- VECTERR? u
[%/0.01 %]
Peak Vector Error --- PVECTERR? u
[%/0.01 %]
Phase Error --- PHASEERR? u
[deg/0.01 deg]
Magnitude Error --- MAGTDERR? u
[%/0.01 %]
Origin Offset --- ORGNOFS?
[dB/0.01 dB]
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
TX Power --- TXPWR? DBM
[dBm/0.01 dBm]
--- TXPWR? WATT
[W/(Note 1)]
Note 1:
Denoted by 3 effective digits such as X.XX E± 66XX [W]
RemarksQuery Msg
Intermediate
class
Function Program Msg
Response
Msg
Function
details
2.5 Device Message List
