Anritsu MT8801C - Page 347

Section 2 Device Messages
2-22
(4) Power Meter screen commands
• Program Msg of the Power Meter screen commands are valid only at Power Meter screen.
Query Msg of the Power Meter screen commands are valid at all the screens of the
TX/RX measurement screens.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Measure Mode Power Measure Method Power Meter PMTH POW PMTH? POW
IF Level Meter PMTH IF PMTH? IF
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Other Power Control Bit Pattern Closed Loop PWRCBPAT CLP PWRCBPAT? CLP
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Alternative PWRCBPAT ALT PWRCBPAT? ALT
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
All ‘0’ PWRCBPAT ALL0 PWRCBPAT? ALL0
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
All ‘1’ PWRCBPAT ALL1 PWRCBPAT? ALL1
Auto PWRCBPAT AUTO PWRCBPAT? AUTO
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Closed Loop Up CLOSEDLOOP UP --- ---
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Power Control Down CLOSEDLOOP DOWN --- ---
User Define Leve CLOSEDLOOP USERLVL --- --- Note 2
IF Level Meter Data IFLVLFRM n IFLVLFRM? n n:1 to 10
Count Frame
Disable IF Level Meter On PWRMTRDISP ON PWRMTRDISP? On Note 4
Meas. Result Dislpay Update Off PWRMTRDISP OFF PWRMTRDISP? Off
Calibration Power Meter Calibration (IF Level) PWRCAL CALVAL? [dB/0.01 dB]
Internal Osc. Calibration (IF Level) OSCCAL CALVAL? [dB/0.01 dB]
Calibration Cancel (IF Level) CALCANCEL --- ---
Level Calibration (IF Level) LVLLINEACAL LVLLINEACAL ? [dBm/0.001 dB]
Linearity Calibration Cancel LVLLINEACANCEL
Calibration (IF Level)
Adjust Range Adjust Range ADJRNG --- ---
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Storage Mode Storage Mode (IF Level) Normal STORAGE NRM STORAGE? NRM
Average STORAGE AVG STORAGE? AVG
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Average Count (IF Level) AVR n AVR? n n:2 to 9999
VAVG n VAVG? n n:2 to 9999
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Refresh Interval (IF Level) Every INTVAL EVERY INTVAL? EVERY
Once INTVAL ONCE INTVAL? ONCE
Range Range Up (Power Meter) RNG UP --- ---
Range Down (Power Meter) RNG DN --- ---
Range 0dBm (Power Meter) RNG 1 --- --- Note 3
Range -20dBm (Power Meter) RNG 1 --- ---
Range 10dBm (Power Meter) RNG 2 --- --- Note 3
Range -10dBm (Power Meter) RNG 2 --- ---
Range 20dBm (Power Meter) RNG 3 --- --- Note 3
Range 0dBm (Power Meter) RNG 3 --- ---
RemarksQuery Msg
Intermediate
class
Function Program Msg
Response
Msg
Function
details
