Section 4 Operation
4-24
(3) Correcting RF cable loss when conducting the transmitter mea-
surement: Setting User Cal Factor
When conducting transmitter measurement, set the loss of the RF cable connect-
ing the MT8801C and transmitter under test as a correction value (User Cal
Factor) to measure RF power in the transmitter under test.
Step Key operation Description
1. [Main Func on off] F6 Sets Main Func on to display the Main Menu at the bottom of the screen.
2. [TX&RX Tester] F1 Sets TX&RX Tester mode.
The Setup Common Parameter screen appears.
3. [TX Measure] F1 Displays the first page of the TX Measure menu.
Next Menu [ ] Displays the second page of the TX Measure menu.
[Setup TX Parameter] F9 Displays the Setup TX Measure Parameter screen.
4. Cursor [ ] [ ] Moves the cursor to User Cal Factor.
5. [Set][-/+][0][1] to [F/9][BS] Enter the RF cable loss.
Example: For 5 dB loss, enter 5.00 dB.
7. [Enter] Defines the entered value.
8. [Back Screen] F12 Returns to the Setup Common Parameter screen.
In receiver measurement, perform the same operation to set the User Cal Factor.
Step Key operation Description
1. [Main Func on off] F6 Sets the Main Func on to display the Main Menu at the bottom of the screen.
2. [TX&RX Tester] F1 Sets the TX&RX Tester mode.
The Setup Common Parameter screen appears.
3. [RX Measure] F2 Displays the first page of the RX Measure menu.
Next Menu [ ] Displays the second page of the RX Measure menu.
[Setup RX Parameter] F9 Displays the Setup RX Measure Parameter screen.
4. Cursor [ ] [ ] Move the cursor to User Cal Factor.
5. [Set] [-/+][0][1] to [F/9][BS] Enter the RF cable loss.
Example: For 5 dB loss, enter 5.00 dB.
6. [Enter] Defines the entered value.
7. [Back Screen] F12 Returns to the Setup Common Parameter screen.
