4-63
4.3 CDMA Transmitter and Receiver Test --- TX and RX Tester Mode
(3) Gated output power measurement: Gated Power screen
Measure the Gated output power (in-burst power) of the transmitter with the
parameters specified on the Setup Common Parameter screen (Section 4.3.5)
and Setup TX Measure Parameter screen (Section 4.3.6, (1)).
For the burst signal measurement, the template (magnitude standard line) of the
Gated output power waveform can be set (on Setup Template screen). One hun-
dred types of templates can be saved on floppy disk (3.5-inch) (on Save Tem-
plate screen) and recalled (on Recall Template screen).
Note that a template can be displayed only when a relative level mode is set at
burst signal measurement.
Note:
On the Gated Power screen, the power sensor is not used; the internal IF
level is used to measure the power.
• Display the Gated Power screens according to the following steps:
Step Key operation Description
1. [Main Func on off] F6 Sets the Main Func on to display the Main Menu at the bottom of the screen.
2. [TX&RX Tester] F1 Sets TX&RX Tester mode.
The Setup Common Parameter screen appears.
3. [TX Measure] F1 Displays the first page of the TX Measure menu.
4. Next Menu [ ] Displays the second page of the Main Func menu.
5. [Start] F5 Sets Call Processing state to Idle.
6. Connect call. Turn on the power of the mobile station under test.
Wait until the Call Processing state becomes Idle (Regist) after Registration.
7. [NW Originate] F2 Sets Call Processing state to Loop Back.
8. [Gated Power] F9 Displays the Gated Power screen.
