Section 4 Operation
4-106
4.3.7 Analog transmitter measurement
Set Control Band to A800MHz on the Setup Common Parameter screen, then press
the [TX Measure] F1 main function key to set analog transmitter measurement mode.
This paragraph describes the following analog transmitter measurement items:
1. Setting parameters (Setup Analog TX Measure Parameter screen)
2. Signal generator + analog transmitter measurement (Analog TX Meas with SG
screen)
(1) Setting the parameters: Setup Analog TX Measure parameter
screen
Set the Analog transmitter measurement parameters on Setup Analog TX Mea-
sure Parameter screen.
measurements.
Switch to the Setup Analog TX Measure Parameter screen according to the fol-
lowing steps:
Step Key operation Description
1. [Main Func on off] F6 Sets Main Func on to display the first page of the Main Menu at the bottom of
the screen.
2. [TX&RX Tester] F1 Sets the TX&RX Tester mode.
The Setup Common Parameter screen appears.
3. Cursor [ ][ ][ ][ ] Move the cursor to Control Band.
[Set] [ ][ ] [Set] Select A800 MHz and press the [Set] key to validate it.
4. [TX Measure] F1 Displays the first page of the TX Measure menu.
5. Next Menu [ ] Displays the second page of the TX Measure menu.
6. [Setup Analog TX Parameter] F9
Displays the Setup Analog TX Measure Parameter screen.
