(4) Example of receiver measurement (FER measurement)
An example of receiver measurement (FER measurements) on the CDMA mo-
bile station is given below.
1. Setup
As described in paragraph 4.3.1 (1), connect the MT8801C to the measured
equipment (mobile station).
2. Measurement Setting Procedure
Set the receiver measurement (FER measurements) of the MT8801C in the fol-
lowing steps:
Step Operation
(Checking and setting the measurement interface)
1. Press function key F6 (Main Func) to turn on the Main Func.
2. Press the Next Menu key [ ] and function key F2 (Instrument Setup) in this order to switch to the
Instrument Setup screen.
3. Check that the RF Input/Output item is set to “Main.”
4. Press function key F6 (Main Func) to turn on the Main Func.
5. Press function key F1 (TX/RX Measure) to enter TX/RX Measure mode (Setup Common
Parameter screen).
(Setting the Setup Common Parameter screen)
6. Sets the specification using the current specification.
7. Set the measurement frequency or channel. (Example: Set Band to 800 MHz and Channel to
1CH.)
8. Set the Reference Level and BS Output Level.
9. For the type of signal of the measuring object, set each the item (Service Option etc.) of the signal.
(Setting the Setup RX Measure Parameter screen)
10. Press function key F2 (RX Measure) to enter RX measurement mode.
11. Press the Next Menu key [ ] and function key F9 (Setup RX Measure Parameter) to switch to the
Setup RX Measure Parameter screen.
12. Set the FER Parameter items. (See paragraph 4.3.7 (1).)
13. Set the User Cal Factor if required. (See paragraph 4.3.1 (3).)
14. Press function key F12 (Back Screen) to return to the Setup Common Parameter screen.
(Setting the Setup Call Processing Parameter screen)
15. Press function keys F3 (Call Processing) and F9 (Setup Call Proc. Parameter) in this order to switch
to the Setup Call Processing Parameter screen.
16. Set SID, NID, and BASE_ID.
17. Press function key F12 (Back Screen) to return to the Setup Common Parameter screen.
