5-13
(13) The Open Loop Time Response screen (shown below) is displayed.
(14) Press the key of Next Menu to display the second page of function keys (F7
to F12).
(15) Press the F7 (Step Value) key and input 20.0 dBm using the numeric keypad.
(16) Press the key of Next Menu to display the first page of function keys (F7 to
F12).
(17) Press the F9 (Marker) key and F7 (Normal) key to set Marker to be Normal.
(18) Press the F12 (return) key.
(19) Press the F7 (BS Level Step Up Start) key.
(20) When you press the F7 (BS Level Step Up Start) key, the time response mea-
surement is started for the first transition of the CDMA base station power out-
put. The measurement result during the first transition is shown as follows:
5.2 Testing CDMA Mobile station Output
