B-7
• Analog RX Measure screen
Item Initial value Initialization
• Main function key :
First page
[RF Level On Off]F4 Off PS
• AF Level function key :
First page
[HPF]F9 Off PW
[LPF]F10 Off PW
[Filter]F11 Off PW
Second page
[Strage Mode]F9 Normal PS
[Average Count]F9 10 PS
[AF Level Unit]F10 V PS
[Distortion Unit]F11 % PS
• RF Frequency function key :
[Incremental Step Value]F7 1.000 000 MHz PS
[Relative On Off]F8 Off PS
[Channel]F9 1 CH PW
• RF Level function key :
[Incremental Step Value]F7 1.0 dB PS
[Relative On Off]F8 Off PS
[Unit EMF TERM]F10 EMF PS
• Modulation function key :
First page
[AF Osc.1 Frequency]F8 1.0040 kHz PW
[AF Osc.1 Deviation]F9 8.00 kHz PW
[AF Osc.1 On Off]F11 On PS
Second page
[AF Osc.2 Signal]F7
[AF Signal]F7 Tone PW
[Output for Mod AF]F8 Mod PW
[AF Osc.2 Frequency]F8 1.0040 kHz PW
[AF Osc.2 Deviation]F9 8.00 kHz (only for AF Osc.2 Signal=Mod) PW
[AF Osc.2 Level]F10 100.0 mV (only for AF Osc.2 Signal=AF) PW
[AF Osc.2 On Off]F11 Off PS
Third page
[External Deviation]F9 8.00 kHz PW
[External On Off]F11 Off PS
Appendix B Initial Values
