2-25
(6) Setup Template screen commands
• Setup Template screen commands are valid at all the screens of the TX/RX mea-
surement screens (screens under the Setup Common Parameter screen).
Template Save Template File No. SAVETEMP n --- --- n:0 to 99
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Recall Template File No. SLCTTEMP n SLCTTEMP? n n:0 to 99
RCLTEMP n --- --- n:0 to 99
Default Standard SLCTTEMP STD SLCTTEMP? STD
Level Line Level 1 TEMPLVL 1, TEMPLVL? 1 [dB/0.1dB] :-90.0 to 10.0
Line Level 2 TEMPLVL 2,
TEMPLVL? 2 [dB/0.1dB] :-90.0 to 10.0
(7) Open Loop Time Response screen commands
• Program Msg of the Open Loop Time Response screen commands are valid only at
Open Loop Time Response screen.
Query Msg of the Open Loop Time Response screen commands are valid at all the
screens of the TX/RX measurement screens.
Start Step Up Measure Start STEPUPSA --- ---
Step Down Measure Start STEPDNSA --- ---
Calibration Internal Osc. Calibration OSCCAL CALVAL? [dB/0.01 dB]
Calibration Cancel CALCANCEL --- ---
Measure Status BS Power Up Meas --- OLPCSTAT? UPM
BS Power Up Ready --- OLPCSTAT? UPR
BS Power Up Meas/Down Ready --- OLPCSTAT? UPMDNR
BS Power Down Meas --- OLPCSTAT? DNM
BS Power Down Ready --- OLPCSTAT? DNR
BS Power Up Ready/Down Meas --- OLPCSTAT? UPRDNM
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Marker Mode Normal MKR NRM MKR? NRM
Off MKR OFF MKR? OFF
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Position MKRP t MKRP? t [ms/0.5 ms] t:0 to 100 ms
MKN t MKN? t [ms/0.5 ms] t:0 to 100 ms
Level Step Value STEPVAL STEPVAL? [dB/0.1 dB] :10.0 to 20.0 dB
Step Up Total Level STEPUP --- ---
Step Down Total Level STEPDN --- ---
BS Output Power Cal BS Output Power Cal OLVLCAL --- ---
Result Initial Level --- INITLVL? [dBm/0.1 dBm]
Current Level --- CURRLVL? [dBm/0.1 dBm]
Marker --- MKL? [dB/0.1 dB]
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Judge (each point of Marker) PASS --- MKRPASS? PASS
FAIL --- MKRPASS? FAIL
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Judge (Total) PASS --- TEMPPASS? PASS
FAIL --- TEMPPASS? FAIL
RemarksQuery Msg
Intermediate class
Function Program Msg
Response
Msg
Function details
RemarksQuery Msg
Intermediate
class
Function Program Msg
Response
Msg
Function
details
2.5 Device Message List
