2-33
AF Oscillator 1 Frequency AFREQ1 f AFREQ1? f[Hz / 0.1Hz]
(Mod.)
Deviation ADEV1 f ADEV1? f[Hz / 0.1Hz]
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Oscillator Switch On AOUT1 ON AOUT1? ON
Off AOUT1 OFF AOUT1? OFF
AF Oscillator 2 Frequency AFREQ2 f AFREQ2? f[Hz / 0.1Hz]
(Mod./AF)
Deviation ADEV2 f ADEV2? f[Hz / 0.1Hz]
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Level ALVL2 vV(V,MV,UV) ALVL2? V v[V / 1µV]
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
ALVL2 DBM ALVL2? DBM [dBm / 0.1dB]
ALVL2 (or ALVL2 v) ALVL2? (or v)
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Signal Tone ASIG2 TONE ASIG2? TONE
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Noise(ITU-T G.227) ASIG2 G227 ASIG2? G227
Noise(White) ASIG2 WHITE ASIG2? WHITE
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Output For Mod/AF Mod. AOPF2 MOD AOPF2? MOD
AF AOPF2 AF AOPF2? AF
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Oscillator Switch On AOUT2 ON AOUT2? ON
Off AOUT2 OFF AOUT2? OFF
External Oscillator Deviation ADEVX f ADEVX? f[Hz / 0.1Hz]
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
(Mod.) Oscillator Switch On AOUTX ON AOUTX? ON
Off AOUTX OFF AOUTX? OFF
Measure Result RF Frequency --- RFFREQ? f[Hz / 0.01Hz]
RF Frequency Error --- RFFREQERR? f[Hz / 0.01Hz]
RF Freq. Error ppm --- RFFREQERRPPM? m[ppm / 0.0001ppm]
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
RF Power --- RFPWR? W w[W / 1pW]
--- RFPWR? DBM [dBm / 0.01dB]
Relative Value --- RFPWRRLV? [dB / 0.01dB]
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Deviation Demod. FM --- RDEV? f[Hz / 0.1Hz]
Demod. øM --- RDEV? r[rad / 0.0001rad]
Relative Value --- RDEVRLV? [dB / 0.01dB]
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Deviation Demod. FM --- RDEVALL? f[Hz / 0.1Hz] *1
Demod. øM --- RDEVALL? r[rad / 0.0001rad]
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
AF Level Demod. FM --- TALVL? f[Hz / 0.1Hz]
Demod. øM --- TALVL? r[rad / 0.1rad]
Relative Value --- TALVLRLV? [dB / 0.01dB]
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
AF Level Demod. FM --- TALVLALL? f[KHz / 0.1KHz] *2
Demod. øM --- TALVLALL? r[rad / 0.0001rad]
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Distortion --- DSTN? DB [dB / 0.01dB]
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
--- DSTN? PER p[% / 0.01%]
--- DSTN? Output with current selected unit.
AF Frequency --- AFFREQ? f[Hz / 0.001Hz]
Freq. Characteristics --- FREQCHAR? n [dB / 0.01dB] *3
Intermediate
class
Function Function details Program Msg Query Msg
Response
Msg
Remarks
Specifies the input level with
dBm unit.
Specifies the input level with
dBu unit.
Specifies the input level with
current selected unit.
Readouts all the
measured results.
Readouts all the
measured results.
2.5 Device Message List
