4-39
4.3 CDMA Transmitter and Receiver Test --- TX and RX Tester Mode
Call Proc. state: Loop Back, Conversation, CDMA mode
1 21
Main Func
On Off
1
MT8801 99-12-31 12:00:00
<< Setup Common Parameter (CDMA) >> Call Proc. : Loop Back
TX
Measure
RX
Measure
Call
Processing
TX Measure TX Measure
Setup
TX Parameter
DUT Control (Tester Mode) : (Call Proc.)
Using Specification : [IS-95A ]
Frequency
Band Traffic Band : [C800MHz] Control Band : [C800MHz]
CDMA Channel : [ 1CH] TX Meas. ( 825.030000MHz)
RX Meas. ( 870.030000MHz)
Analog Traffic Channel : [ 1CH] TX Meas. ( 825.030000MHz)
RX Meas. ( 870.030000MHz)
Analog Control Channel : [ 1CH]
Level
Reference Level : [ 30.0dBm] Auto Set : [Off]
BS Output Level (Total) : [ -55.0dBm]
AWGN Level : [-20.0dB] = ( -75.0dBm) : [Off]
Access Parameter NOM_PWR : [ 0dB]
Access Parameter INIT_PWR : [ 0dB]
MS Power Level(VMAC) : [ 2]
Signal
Service Option : [SO2 ]
Data Rate : [Full]
Call Drop Threshold : [On ][250Frames]
Echo Delay : [1sec]
->
Setup
Gated Power
Template
->
Modulation
Analysis
->
Gated Power
->
Power
Meter
->
Open Loop
Power Cont.
->
2
2
Occupied
Bandwidth
->
Spurious
Emission
->
Spurious
close to
the Carrier
->
MSID Information
MSID: (----3E7F9EBE7)H
ESN : (FFFFFFFF)
Fig. 4-4 (7/18) Setup Common Parameter Screen (TX Measure)
1 21
Main Func
On Off
1
MT8801 99-12-31 12:00:00
<< Setup Common Parameter (CDMA) >> Call Proc. : Loop Back
TX
Measure
RX
Measure
Call
Processing
RX Measure RX Measure
Setup
RX Parameter
DUT Control (Tester Mode) : (Call Proc.)
Using Specification : [IS-95A ]
Frequency
Band Traffic Band : [C800MHz] Control Band : [C800MHz]
CDMA Channel : [ 1CH] TX Meas. ( 825.030000MHz)
RX Meas. ( 870.030000MHz)
Analog Traffic Channel : [ 1CH] TX Meas. ( 825.030000MHz)
RX Meas. ( 870.030000MHz)
Analog Control Channel : [ 1CH]
Level
Reference Level : [ 30.0dBm] Auto Set : [Off]
BS Output Level (Total) : [ -55.0dBm]
AWGN Level : [-20.0dB] = ( -75.0dBm) : [Off]
Access Parameter NOM_PWR : [ 0dB]
Access Parameter INIT_PWR : [ 0dB]
MS Power Level(VMAC) : [ 2]
Signal
Service Option : [SO2 ]
Data Rate : [Full]
Call Drop Threshold : [On ][250Frames]
Echo Delay : [1sec]
->
Setup
Signal
->
FER
Measure
->
2
2
MSID Information
MSID: (----3E7F9EBE7)H
ESN : (FFFFFFFF)
Fig. 4-4 (8/18) Setup Common Parameter Screen (RX Measure)
