2.4 General system description
2.4.1 General description of the drill rig
This drill rig is a fully diesel-hydraulic drill rig designed for surface drilling applications such
as in quarries and on construction sites.
The drill rig consists of the following main components: (See illustration under General De-
scription)
General Description
1 Control panel for diesel engine and directional in-
strument
2 Emergency stop
3 Operator's panel
4 Air conditioning/Heating (Drill rigs with cabin)
5 Batteries
6 Diesel engine
