SmartROC D65 T4F 7 Before drilling
88 No: 713944459.6 en
7.3 Setting feed pressure
Examples of settings of Feed pressure.
n Change setting of Drill bit: Press Enter to display a drop-down menu. Then use the
arrow keys up/down (on the display screen) and select the desired setting, confirm
with Enter. E.g. as follows:
l Different type of drill bit
l Different operator settings
l Different feed pressures can be changed so that they suit various local condi-
tions.
Symbol Explanation
Drill bit. This symbol is next to various parameters
and indicates that they are drill bit specific. The
symbol can also be found together with a list of
options from which the desired type of drill bit can
be selected.
Table22: Symbols
7.4 Loading the rod carousel
1.
Activate drilling with button (4)
