SmartROC D65 T4F 8 Drilling
103 No: 713944459.6 en
8.1.4 Direct selection menu F1.
Direct selection menu F1.
Symbol description for direct selection menu F1
!
NOTE: GPS is covered separately in the chapter entitled Options
The following is an explanation of the symbols shown in direct selection menu F1.
Symbol Name Explanation
Air pressure Shows the current pressure in
the pressure tank (Bar)
Water mist Shows current flow to water mist
system (%)
Lubrication oil pressure Shows the current lubrication oil
pressure to the drill hammer
(Bar)
Resetting hole length Zeroes the measured hole
length. Length measurement
should be reset with the drill bit
against the ground before begin-
ning to drill a new hole.
