SmartROC D65 T4F 9 Angle instruments
117 No: 713944459.6 en
9 Angle instruments
9.1 Angle, depth and laser instrument
Depending on the equipment level chosen, the drill rig can be equipped with one of the fol-
lowing alternatives:
n Angle instrument with aim device (standard equipment).
n GPS compass (option).
n Laser plane instrument (option).
In all cases, the system consists of a number of sensors in the cabin and boom - feed sys-
tem. The sensors are connected to the I/O unit and the LCD display through CAN BUS
communication. The system is presented and operated from the cabin's LCD display.
9.1.1 Angle instrument with sight
This drill rig is equipped with an electronic angle indication system consisting of an angle
sensor on the boom and feeder, aim device and graphic presentation on an LCD display.
The aim device makes it possible to drill parallel holes by selecting a reference point before
the first hole is drilled. This reference point is then maintained throughout the entire round
or as long as the direction of movement is the same. By turning the aim device back to the
same reference point the entire time regardless of how the rig travels, the instrument calcu-
lates how the feed inclination must be changed to maintain the same direction of move-
ment. The angle sensor on the boom mounting allows the instrument to compensate for
the turning of the boom the same way as when the aim device is turned.
9.1.2 Angle instrument menu
The angle instrument is accessed by pressing the F4 button in the left-hand edge of the
display. These four buttons always provide direct access to the respective functions, i.e.
you do not need to use the ESC key to go back to the main menu to select them.
