SmartROC D65 T4F 8 Drilling
96 No: 713944459.6 en
!
NOTE: Notice! Use the lever proportionally forward, until the drill bit
has entered into solid rock before locking collaring.
10.
Full drilling can be activated after reaching homogenous rock or once the drill bit has
entered far enough into the rock.
11.
Activate full drilling, drill lever position (f2), and hold the lever there for two seconds.
When this happens, the green information box will be activated in the status bar on
the display (see figure: menu F1).
!
NOTE: To check that crushed rock is flushed up properly from the hole, the suction
hood should be raised now and then.
!
NOTE: Notice! If water flushes out of the hole, turn off the dust collector. Button (8).
!
NOTE: Moving the drilling lever to position (f2) switches between reduced and full
drilling.
8.1.2 One hole automatics (OHA)
The OHA function enables the rig to drill automatically to a desired depth and then extract
the rods from the hole. OHA is activated by pressing button 2.
