Diode with engine symbol illuminates.
n If battery voltage is connected (contact +15), the diode with the battery symbol will illu-
minate.
Fig. 14 - Timer LEDs and rotary switches
1 Battery diode
2 Rotary switch for pause time
3 Rotary switch for running time
4 Engine diode
5 Push button for test/extra lubrication
