SmartROC D65 T4F 5 Controls

57 No: 713944459.6 en

4 Hydraulic pump 4: Positioning

5 Hydraulic pump 5: Radiator - hydraulics, com-

pressor and diesel engine

6 Hydraulic pump 6: Radiator - diesel engine

7 Pilot pressure

8 Not used

Table16: Test connections
