Version 5.8 143 September 2009
SIP User's Manual 3. Web-Based Management
To configure the Authentication Table:
1. Set the 'Authentication Mode' parameter to 'Per Endpoint' (refer to ''Configuring Proxy
and Registration Parameters'' 94 on page ).
2. Open the 'Authentication' page (Configuration tab > Protocol Configuration menu >
Endpoint Settings submenu > Authentication
Figure 3-82: Authentication Page
page item).
3. In the 'User Name' and 'Password' fields corresponding to a port, enter the user name
and password respectively.
4. Click the Submit
5. To save the changes to flash memory, refer to ''
button to save your changes.
Saving Configuration'' 167 on page .
3.3.4.9.2 Configuring Automatic Dialing
The 'Automatic Dialing' page allows you to define a telephone number that is automatically
dialed when an FXS or FXO port is used (e.g., off-hooked).
Notes:
• After a ring signal is detected on an 'Enabled' FXO port, the device
initiates a call to the destination number without seizing the line. The line
is seized only after the call is answered.
• After a ring signal is detected on a 'Disabled' or 'Hotline' FXO port, the
device seizes the line.
• You can also configure automatic dialing using the ini
• You can configure the device to play a Busy/Reorder tone to the Tel side
upon receiving a SIP 4xx, 5xx, or 6xx response from the IP side (i.e., Tel-
to-IP call failure), using the
file table parameter
TargetOfChannel.
ini file parameter FXOAutoDialPlayBusyTone
(refer to ''SIP Configuration Parameters'' 252 on page ).
