3.2.3 Resetting an Analog Channel
The 'Home' page allows you to inactivate (reset) an FXO or FXS analog channel. This is
sometimes useful in scenarios, for example, when the device (FXO) is connected to a PBX
and the communication between the two can't be disconnected (e.g., when using reverse
polarity).
 To reset a channel:
 Click the required FXS or FXO port icon, and then from the shortcut menu, choose
Reset Channel
Figure 3-34: Shortcut Menu for Resetting a Channel (e.g. MP-11x Home Page)
; the channel is changed to inactive (i.e., the port icon is displayed in
grey).
