SIP User's Manual 58 Document #: LTRT-65412
MP-11x & MP-124
3.3 Configuration Tab
The Configuration tab on the Navigation bar displays menus in the Navigation tree related
to device configuration. These menus include the following:
 Network Settings (refer to ''Network Settings'' 58 on page )
 Media Settings (refer to ''Media Settings'' 68 on page )
 Security Settings (refer to ''Security Settings'' 73 on page )
 Protocol Configuration (refer to ''Protocol Configuration'' 90 on page )
 Advanced Applications (refer to ''Advanced Applications'' 153 on page )
3.3.1 Network Settings
The Network Settings menu allows you to configure various networking parameters. This
menu includes the following items:
 IP Settings (refer to ''Configuring the Multiple Interface Table'' 58 on page )
 Application Settings (refer to ''Configuring the Application Settings'' 62 on page )
 IP Routing Table (refer to ''Configuring the IP Routing Table'' 65 on page )
 QoS Settings (refer to ''Configuring the QoS Settings'' 67 on page )
3.3.1.1 Configuring the Multiple Interface Table
The 'Multiple Interface Table' page allows you to configure up to 16 logical network
interfaces, each with its own IP address, unique VLAN ID (if enabled), interface name, and
application type permitted on the interface:


Control

Media
This page also provides VLAN-related parameters for enabling VLANs and for defining the
'Native' VLAN ID (VLAN ID to which incoming, untagged packets are assigned). For
assigning VLAN priorities and Differentiated Services (DiffServ) for the supported Class of
Service (CoS), refer to “Configuring the QoS Settings” on page
Operations, Administration, Maintenance and Provisioning (OAMP)
67.
Notes:
• For a detailed description with examples for configuring multiple network
interfaces, refer to ''Network Configuration'' 454 on page ).
•
• You can also configure this table using the
Once you access the 'Multiple Interface Table' page, the 'IP Settings'
page is no longer available.
ini file table parameter
InterfaceTable (refer to ''Networking Parameters'' 213 on page ).
• You can view all configured IP interfaces that are currently active in the
'IP Active Interfaces' page (refer to ''Viewing Active IP Interfaces''
178
on
page ).
