AudioCodes Mediant 3000 User Manual

User's Manual 252 Document #: LTRT-89730
Mediant 3000
Table 16-4: LDAP Configuration Table Parameter Descriptions
Parameter Description
Index
[LdapConfiguration_Inde
x]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
LDAP Servers Group
[LdapConfiguration_Grou
p]
Assigns the LDAP server to an LDAP Server Group, configured in the
LDAP Server Groups table (see ''Configuring LDAP Server Groups'' on
page 248).
Notes:
 The parameter is mandatory and must be set before configuring the
other parameters in the table.
 Up to two LDAP servers can be assigned to the same LDAP Server
Group.
LDAP Server IP
[LdapConfiguration_Ldap
ConfServerIp]
Defines the IP address of the LDAP server (in dotted-decimal notation,
e.g., 192.10.1.255).
By default, no IP address is defined.
Notes:
 The parameter is mandatory.
 If you want to use an FQDN for the LDAP server, leave the parameter
undefined and configure the FQDN in the 'LDAP Server Domain Name'
parameter (see below).
LDAP Server Port
[LdapConfiguration_Ldap
ConfServerPort]
Defines the port number of the LDAP server.
The valid value range is 0 to 65535. The default port number is 389.
LDAP Server Max
Respond Time
[LdapConfiguration_Ldap
ConfServerMaxRespond
Time]
Defines the duration (in msec) that the device waits for LDAP server
responses.
The valid value range is 0 to 86400. The default is 3000.
Note: If the response time expires, you can configure the device to use its
local database (Web Users table) for authenticating the user. For more
information, see ''Configuring Local Database for Management User
Authentication'' on page 260.
LDAP Server Domain
Name
[LdapConfiguration_Ldap
ConfServerDomainName
]
Defines the domain name (FQDN) of the LDAP server. The device tries to
connect to the LDAP server according to the IP address listed in the
received DNS query. If there is no connection to the LDAP server or the
connection to the LDAP server fails, the device tries to connect to the
LDAP server with the next IP address in the DNS query list.
Note: If the 'LDAP Server IP' parameter is configured, the 'LDAP Server
Domain Name' parameter is ignored. Thus, if you want to use an FQDN,
leave the 'LDAP Server IP' parameter undefined.
LDAP Password
[LdapConfiguration_Ldap
ConfPassword]
Defines the user password for accessing the LDAP server during
connection and binding operations.
 LDAP-based SIP queries: The parameter is the password used by the
device to authenticate itself, as a client, to obtain LDAP service from
the LDAP server.
 LDAP-based user login authentication: The parameter represents the
login password entered by the user during a login attempt. You can
use the $ (dollar) sign in this value to enable the device to
automatically replace the $ sign with the user's login password in the
search filter, which it sends to the LDAP server for authenticating the
