AudioCodes Mediant 3000 User Manual

Version 7.0 691 Mediant 3000
User's Manual 44. Software Upgrade
• Tel-to-IP Calls: Maps the calling (source) PBX extension to the "global" number.
For example, if the device receives a Tel call from PBX extension 402, it changes
this calling number to 638002, and then sends call to the IP side with this calling
number. In addition to the "global" phone number, the display name (caller ID)
configured for the PBX user in the User Info table is used in the SIP From header.
Note: If you have configured regular Tel-to-IP manipulation rules (see ''Configuring
Source/Destination Number Manipulation'' on page 469), the device applies these
rules before applying the mapping rules of the User Info table.

Registering Users: The device can register each PBX user configured in the User
Info table. For each user, the device sends a SIP REGISTER to an external IP-based
Registrar server, using the "global" number in the From/To headers. If authentication
is necessary for registration, the device sends the user's username and password,
configured in the User Info table, in the SIP MD5 Authorization header.
You can configure up to 5,000 mapping rules in the GW User Info table. These rules can
be configured using any of the following methods:

Web interface - see ''Configuring GW User Info Table through Web Interface'' on page
691

Loadable User Info file - see ''Configuring GW User Info Table in Loadable Text File''
on page
693
Notes:
• To enable user registration, set the following parameters on the Proxy &
Registration page (Configuration tab > VoIP menu > SIP Definitions > Proxy &
Registration) as shown:
√ 'Enable Registration': Enable (IsRegisterNeeded is set to 1).
√ 'Registration Mode': Per Endpoint (AuthenticationMode is set to 0).
44.1.7.2.1 Configuring GW User Info Table through Web Interface
The following procedure describes how to configure and register users in the GW User Info
table through the Web interface.
Note: If a User Info file is loaded to the device (as described in ''Configuring GW
User Info Table in Loadable Text File'' on page 693), all previously configured entries
are removed from the table in the Web interface and replaced with the entries from
the loaded User Info file.
 To configure the GW User Info table through the Web interface:
1. Open the GW User Info table (Configuration tab > VoIP menu > SIP Definitions >
User Information > GW User Info Table).
