Avaya


Definity User Manual

Field Names and Descriptions
Issue 3 May 2002
4-43
CV/LAN Administration — Assign Port for
Node ID signalXX
Screen 4-22. Assign Port for Node ID signalXX
NOTE:
This screen will appear only if CV/LAN is also installed.
This screen is used to assign a DEFINITY system virtual BRI port number to a
node ID number. Only port numbers which are assigned to the CV/LAN
application and are not assigned to other node ID numbers, will appear in the
list.
Use this screen as follows:
1. Press or use the arrow keys to move the cursor to the port number
you want to assign (port 00 is used to unassign the node ID), and then
press .
2. The following prompt appears:
Are you sure? (Y/N). Type Y and
press .
If you type N the cursor reappears where it was and the port number is not
changed.
3. Then press and the previous screen will appear.
Field Name Description
signalXX Read-only. Node ID number used by CV/LAN clients.
Available Ports Port number used on the DEFINITY system. Valid range is 1 to 12.
This line is used to provide abbreviated help on the currently selected field.
CV/LAN Administration
CANCEL REFRESH ASSIGNHELP
Assign Port For Node ID signalXX
Currently Assigned to Port __
Available Ports
00 (unassign)
__
__
__
__
__
__
__
__
__
__
__
__
TAB
ASSIGN
RETURN
CANCEL
