DLG System Administration
6-44 Issue 3 May 2002
Diagnostics — Hardware Alarms
Screen 6-28. Hardware Alarms
This is a read-only screen that displays any hardware alarms.
NOTE:
Contact the TSC if there are any alarms or if any of the tests fail.
Use this screen as follows:
â– Press to return to the Diagnostics menu.
Field Name Description
TN Code/Vintage Displays the MAPD (TN801B) board code and vintage
as reported by the DEFINITY system.
FW Version Displays the firmware versions.
RM Version Displays the remote maintenance firmware versions.
Alarm Count Displays the number of active alarms followed by a
description of each alarm and its severity.
TN Code/Vintage:
TN801B V1
FW Version:
BOOT=777 APPL=15000
RM Version:
BOOT=0.1.444 APPL=0.1.4
Alarm Count: 2
platform ambient temperature is high [WARNING]
voltage out of range [MINOR]
(EOF):
RETURN
