Field Names and Descriptions
Issue 3 May 2002
6-51
DLG Port Status/Control —
Message Collection Period
Screen 6-32. Message Collection Period
This screen enables you to set the message collection period for a port. When the
screen is first displayed, a port number (1 to 12) replaces xx in the Port field, the
client’s name or IP address replaces yy in the Client field, and the client’s link
replaces zz in the Link field. The port number comes from the previous screen
(whatever port the cursor was on).
After you enter a value for Period on this screen and press the previous
screen reappears with the cursor positioned at the beginning of the new entry.
Changing the collection period clears the traffic counts (messages to the
DEFINITY system and messages from the DEFINITY system) on the DLG Port
Status/Control screen.
Field Name Description
Port The port for which messages are to be collected.
Display-only.
Client The client name or IP address for which messages are to
be collected. Display-only.
Link The client link for which messages are to be collected.
Period The time period (in minutes) during which messages are
to be collected. Range = 1-720. Default = 30.
This line is used to provide abbreviated help on the currently selected field.
DLG Port Status/Control
ENTER CLEARCANCEL REFRESH HELP
Message Collection Period
Port: XX Client: YY Link: ZZ
Period: ____
ENTER
