CVLAN and DLG System Administration
4-38 Issue 3 May 2002
CV/LAN Administration
Screen 4-19. CV/LAN Administration
NOTE:
This screen will appear only if CV/LAN is also installed.
Field Name Description
Node ID Read-only. Node ID used by CV/LAN clients.
Port Port number used on the DEFINITY system. Valid range
is 1 to 12. Each port can only be assigned once.
Heartbeat State The state of the ASAI heartbeat sever for this node ID.
Either ASAI on or off.
Number of Clients The number of clients administered to use this node ID.
CV/LAN Administration
Node ID Port Heartbeat State Number of Clients
signal01 __ ____ ____
signal02 __ ____ ____
signal03 __ ____ ____
signal04 __ ____ ____
signal05 __ ____ ____
signal06 __ ____ ____
signal07 __ ____ ____
signal08 __ ____ ____
CANCEL REFRESH CLIENT PORTHELP STATE
This line is used to provide abbreviated help on the currently selected field.
