Avaya


Definity User Manual

Field Names and Descriptions
Issue 3 May 2002
6-45
Diagnostics — Hardware Status
Screen 6-29. Hardware Status
This is a read-only screen that displays hardware status.
NOTE:
Contact the TSC if any alarms exist or if any tests fail.
Use this screen as follows:
■ Press to return to the Diagnostics menu.
Field Name Description
TN Code/Vintage Displays the MAPD (TN801B) board code and vintage as
reported by the DEFINITY system.
FW Version Displays the firmware version.
RM Version Displays the remote maintenance firmware version.
Alarm count Displays the number of active alarms followed by a
description of each alarm and its severity.
TN Code/Vintage:
TN801B V2
FW Version:
BOOT=PIFN 20496, FW version 16, Dev_id 0, Comp_id 10
:
Active: APPL
APPL=1.0.8
BOOT=1.0.8 (boot)
RM Version:
APPL=PIFN 20496, FW version 16, Dev_id 0, Comp_id 10
-VEE -12.15V -12.60V -11.40V
+VEE +12.10V +11.40V +12.60V
actual min max
Voltages:
Temp2 84.80 deg F 40.00 deg F 158.00 deg F
Temp1 91.64 deg F 40.00 deg F 158.00 deg F
actual min max
Temperatures:
(no alarms)
Alarm Count: 0
RETURN
