Installing the MAPD
2-12 Issue 3 May 2002
Figure 2-7. MAPD System LCD Display
MAPD - Front View
TN801B
8-character LCD
Boot/Shut
Alarm
Flashing
Heartbeat
State of Operation
The second position (alarm) displays a letter indicating the following types of
alarms: warnings (w), minor (m), major (M), and (C) for critical. This
position is blank if there are no alarms
States of Operation (when the MAPD boots, these stated display in the following order)
F
W
B
O
O
T
Firmware board tests
P
C
B
I
O
S
O
S
I
N
I
T
P
G
M
F
W
A
I
N
I
T
A
S
A
I
8
Alarm
MAPD running with 8 links (“8” can be any number
MAPD System Initialization
Pentium Processor Card Diagnostics
Operating System Initialization
Update MAPD Board FLASH PROMS, if necessary
from 1 to 8)
