6.2 Hardware Safety & Mechanical Limits - Core
Safe operation of the AvL antenna system is essential and it is critical that the AAQ software be configured
appropriately. Many limits on motion of the antenna are set by physical switches that are monitored by the
AAQ ACU. Others are set by software configuration parameter values that are compared to a particular
system variable or sensor output. Most of these are set in the factory, not subject to change and require a
high privilege level to view and modify. A small group is subject to change after the antenna leaves the AvL
factory due to later mounting of CFE hardware on the antenna system and installation of the antenna onto
the integrator’s vehicle or base support. It is this small group of parameters that is addressed in this section.
6.2.1 Pedestal Limits
Long name
Level
Type
Value Range
Documentation
Azimuth CCW Limit
4
Float
n/a
The maximum counter clockwise pedestal azimuth
position (Read Only)
Azimuth CW Limit
4
Float
n/a
The maximum clockwise pedestal azimuth position (Read
Only)
Elevation Up Limit
4
Float
n/a
The maximum pedestal elevation position (Read Only)
Elevation Up Stow Limit
4
Float
0.0 to 180.0 (deg)
The maximum elevation for the stow switch position.
Elevation Down Stow Limit
4
Float
-90.0 to 90.0 (deg)
The minimum elevation at the stow position.
Elevation Down Limit
4
Float
-45 to 45 (deg)
Down elevation limit (except stow position) when using a
removable reflector and the reflector is mounted.
Safe Turn Maximum Elevation
4
Float
0 to 180 (deg)
Maximum elevation that is safe to turn in Azimuth
Safe Turn Maximum Elevation
Reflector Mounted
4
Float
0 to 180 (deg)
Maximum elevation that is safe to turn in Azimuth when
using a removable reflector & the reflector is mounted.
User Azimuth CCW Limit
4
Float
-220.0 to 0.0
The maximum counter clockwise pedestal azimuth
position
User Azimuth CW Limit
4
Float
0.0 to 220.0
The maximum clockwise pedestal azimuth position
User Elevation Down Stow
Limit
4
Float
-90.0 to 90.0
The minimum elevation at the stow position
User Elevation Up Limit
4
Float
0.0 to 180.0
The maximum elevation of the positioner
~IMPORTANT~
When the antenna is pointing at low look angles, the movable feed boom, along with
any CFE BUC(s) that may be mounted on it, is located in close proximity to the
stationary base support. Safe elevation angles must be determined for normal
operation of the antenna. This includes movement while the antenna is deployed and
when it reaches the stow position. All elevation angles associated with these
parameters are Ped-EL values, which are referenced to the antenna mechanical
interface and are not subject to adjustment due to tilt compensation. Special attention
