6.3.1 RSL Meter
Minimum value that indicates an RSL signal above noise
RSL Minimum Lock
Threshold
-100000.0 to 100000
Default value: 50
Minimum value that indicates a lock with RSL
Sample time for detecting the signal gradient
Sample time in MS for detecting signal noise
The computer filename for the communications port used
The communications parameters for the com port, in the
form of Baud, Data, Stop & Parity Bits (ie: 9600 8 1 0)
where parity values are 0 for none and 1 for even.
- 100000.0 to 100000
Default value: 1
Value to Divide the rad A/D value to produce a sensor
value. The formula for producing a final value is: ((raw
number*10000)/scale factor)
The RSL power meter is used for broadband signal level detection. Aside from the RSL 1 noise
floor & lock threshold parameters, it is recommended that this device settings are changed only
under the guidance of AvL technical staff.
The RSL Minimum Lock Threshold value determines the Minimum signal strength reported for
detecting a lock signal from a satellite. When this level is reached during a modem scan, the system
will scan at the slow speed.
The RSL 1 Noise Floor value determines the Minimum signal strength above which an RSL signal is
indicated.
6.3.2 Navigation
"NoCompass", "GPS", "Compass",
"Manual", "SatTant",
"VectorCompass"
The device to use as the primary source of the
heading.
"NoCompass", "GPS", "Compass",
"Manual", "SatTant",
"VectorCompass"
The device to use as the heading source if the
primary source fails.
This flag indicated if the heading will be
averaged during the dwell time.
The offset in degrees of the compass device.
Elevation Compass
Position
The Elevation position in degrees, to read the
magnetic compass
"Manual GPS", "Compass GPS", "NAV
RIOM GPS", "Vector Compass GPS"
The device to use as the source of the GPS
location.
Flag indicating that the manual GPS entry
should be used on GPS failure.
