AvL Proprietary and Confidential
Content is Subject to Change without Notice Page 135 of 195
Vector Compass parameters are included to configure and manage the optional high-precision
Vector Compass offered on some AvL antenna systems. The Enable parameter is persistent and
when set insures that the Vector Compass is always powered on and available to the system. When
set and Saved, the Reset parameter causes the Vector Compass to be re-initialized. The parameter
clears automatically (to value = 0) after a successful reset.
6.8.4 Wing System
Wing Elevation Safety Switch is
interlock
Wing Left Stow Switch is
Interlock
Wing Motor Abs Enc Offset
Wing Motor Abs Enc Scale
Factor
Wing Right Deploy Switch is
Interlock
Wing Right Stow Switch is
Interlock
Chapter 7 - Theory of Operation
7.1 Introduction
AvL antenna systems combine the AvL Cable Drive positioning system with a completely automatic
satellite acquisition Antenna Control Unit (ACU) to provide ease of operation without needing a satellite
technician and the ultimate in reliability under even the most demanding environmental conditions.
Our latest line of antenna systems features our AAQ ACU. The AAQ ACU is a robust system offering a
variety of software control functions, high speed sensors, and High-Level integration between hardware
and software. This new system is designed for complete integration into new or existing AvL antenna
systems.
Key Features of the AvL Cable Drive system:
Utilizes highly reliable aircraft control cables in a redundant configuration to achieve zero
backlash
