4.4.3 Profile System
Main Window → View → Configuration, Target
Figure 4.4.3a - Profile System or Configuration Window, Target Tab
The Target / Profile Tab is available via the Configuration window. This page allows the user to view &
make various changes which relate to each of the available system profiles.
Acquisition of a target satellite begins with constructing, or more commonly, editing an existing profile
that is specific for the method and target the user wishes to acquire. Profiles contain all the necessary
parameters for acquisition.
Profile Selection Drop Down
Add (Edit) & Remove Profile
Buttons
Target Specific Parameters
Target Sat. Drop Down Menu
To Next Page
