5.9.2 Simple Profile Example
The “Target” tab of the Configuration window brings us to the Profile “tool” page.
Path
Main Window → View → Configuration, Target tab
Level 1
Figure 5.9.2 – Configuration, Target tab
Note that the factory test profile is shown in the “Profile Name” box.
Next, click “Add” next to the Profile name. The name you choose can be anything which has not
been used before, however certain conventions are recommended:
 Satellite name
 Satellite longitude
 Receive Polarization
 Signaling device - ie: iDirect, Beacon, RSL
 Carrier ID (optional)
