The Feed Bit Override parameter, extends the choices available to the controller outside the
information provided by the feed bit logic output which comes from the feed itself. This also allows
proper use of feeds which do not have feed bit control.
6.4 Automatic Operation - Target
Configuration of the AAQ’s automated features is made on a Target Satellite or Signal Source specific
basis using the Profile System. The steps necessary to create and manage Profiles are described in
Chapters 4 & 5 of this document. In this section, the configuration parameters contained in these
Profiles are detailed.
The Signal Sources and Acquisition Geometry may be defined for each Target Satellite independently by
setting up a Profile. In this way, reliable satellite detection and good signal quality for antenna peaking
purposes can be assured for all satellites of interest.
Without this critical flexibility, antenna performance could be significantly compromised by satellites
that vary widely in their signal characteristics. The parameters and sources that may be tailored for a
specific satellite are accessible through the Profile System window of the AAQRemote GUI. An example
is shown in Figure 6.4.
Figure 6.4 - AAQ Target and Profile System Window
