4.4.11 Graphic Controller Window
Path
Main Window → View → Graphic Controller Window
Level 0
Figure 4.4.11 - Graphic Controller Window
The Graphic Controller Window is a simplified user friendly display of the main window. This window
shows graphically all the necessary inputs and outputs for a normal user to select a Profile & acquire a
satellite. Each graphical area represents a corresponding command or monitor point from the main .NET
GUI window.
