Elevation stow position in degrees if the stow
type is 'Stow at Position'.
Polarization Stow Position
The position in degrees of the pol for the stow
routine.
Enables Auto Stow function when set speed is
reached.
Speed from the GPS to trigger an auto stow.
Time in seconds at the specified speed to trigger
an auto stow.
"Single",
"Multi/Cam", "Stow
At Position", "Up
Position Single
Switch", "Between
Position Single
Switch", "Down
Position Single
Switch"
The type of stow switch configuration installed on
the positioner. (Read Only)
Proper setting of the Stow Position is essential for all AvL antenna systems, as some models use non-
standard type mounting designs. The manual provided with every AvL antenna system provides details
on how the Stow Position should be determined for that antenna.
Once the antenna has been manually placed in the correct Stow Position, the Azimuth, Elevation and
Polarization Stow Position parameter values with Type = Float should be set to match the appropriate
Pedestal angle displayed at that position.
The Azimuth Stow Position parameter with Type = Float, tells the AAQ what position in degrees that the
Stow Routine will be performed.
The Auto Stow On Movement parameter is reserved for vehicular mount antennas. If this is enabled,
any information from the system GPS indicating vehicle motion above a set speed will activate the
antenna stow routine. Speed indication units are determined by the GPS settings.
The Elevation Stow Switch (Read Only) type of stow switch configuration installed on the positioner
6.2.3 Reflector/Feed On/Off
Reflector Mount Azimuth Position
Pedestal Azimuth position for reflector mount or
dismount.
